The firebox / insert INSERT 1000Technical information
Générales
Smoke outlet : 200 mm
Weight : 180 kg
Max logs size : 60 cm
In compliance with : CEN/TS15883
Double combustion : Yes
Size : L 100 x P 51 x H 59 cm
Maximum hourly consumption : 4 kg/h
Type de contrôle de régulation
Régulation manuelle
Seasonal energy efficiency : 66 %
Nominal output : 12 kW
CO Rate : 0,09 %
Particles emission (mg/Nm3) : 30 mg/Nm3
Efficiency : 76,3 %
Damper control
Convection lining
Connectable outside Ø 60
Combustion speed adjustment
Door closure by compression
Door sealed by stainless steel gasket
Automatic door locking when the damper is closed
Infrared integral glass
Ash container with starter
Options :
Grey bricks
