The firebox / insert INSERT 700

Réf : IN0700SF

No reviews so far
Features
The firebox / insert INSERT 700 Technical information

Générales

  • Smoke outlet : 180 mm
  • Weight : 150 kg
  • Max logs size : 50 cm
  • In compliance with : CEN/TS15883
  • Double combustion : Yes
  • Size : L 69,4 x P 45 x H 58,7 cm
  • Maximum hourly consumption : 2,5 kg/h

Type de contrôle de régulation

Régulation manuelle
  • Seasonal energy efficiency : 66 %
  • Nominal output : 7,5 kW
  • CO Rate : 0,07 %
  • Particles emission (mg/Nm3) : 29 mg/Nm3
  • Efficiency : 76,1 %

Damper control Convection lining Connectable outside Ø 60 Combustion speed adjustment Door closure by compression Door sealed by stainless steel gasket Automatic door locking when the damper is closed Infrared integral glass Ash container with starter Options : Grey bricks

INSERT 700
